Standard Management Constant Innovation

Specifications

1. Wire Diameter 0.3mm~0.9mm
2. Aramture Stack Thickness 10~45mm
3. Speed 2500 R.P.M
4. Power Source 1ɸ AC220V 50/60Hz
5. Driving Motor 3 Axis AC Servo Motor
6. Armature Diameter 30~85mm
7. Commutator Diameter 10~35mm
8. Air Pressure 4~5 Kg/cm²
9. Machine Dimension 1600mm(L)*900mm(W)*1700mm(H)

Specifications

1. Wire Diameter 0.4mm~1.2mm
2. Aramture Stack Thickness 15~70mm
3. Speed 3000 R.P.M
4. Power Source 1ɸ AC220V 50/60Hz
5. Driving Motor AC Servo Motor 2000W*2 or AC Servo Motor 400W*2
6. Armature Diameter 25~60mm
7. Commutator Diameter 10~40mm
8. Air Pressure 4~6 Kg/cm²
9. Machine Dimension 2000mm(L)*1850mm(W)*1700mm(H)
